APEX 412EV
The APEX 412EV compact electric excavator features an operating weight of 1000kg, a bucket capacity of 0.025m³, and is powered by a 72V Lithium battery delivering 4kW at 126Ah battery capacity. It offers a digging depth of 1650mm and a digging height of 2550mm
+86 537 2288218
+86 15562359517
Dmachinerygroup@gmail.com

→ Product Description


Bucket Capacity

0.025m³

Chassis Width

930mm

Track Length

1250mm

Gradeability

40°

Chassis Ground Clearance

385mm

Track Width

180mm

Overall Dimension Transport Length

2200*930*2200mm

Excavator Height

2200mm

Battery Capacity Battery Voltage

126Ah 72V

Charging Time

6H-8H

Decibels within 1 meter

<55



Engine

Lithium   Battery

Motor Power

4KW

Power consumption per hour

1KW/h

Max.Digging Height

 2550mm

Max.Dumping Height

1850mm

Max.Digging Depth

16500mm

Max.Digging Radius

2400mm

Turning Radius

1190mm

Bucket excavating force

11KN

Operating Weight

1000kg


Valve

Beifang Brand

Pump

Xingzhou Brand

Double Gear Pump
